USER'S GUIDE
Connectors at Back
Cascade Connectors
A
Serial
B
A serial port connector for SNMP management and maintenance, two (2)
Cascade (bus) connectors, and a power connector are provided at the
back of the StackMaster™TR 16-Port.
NOTE: The AUX connector is intended for future development.
