Appendix C. Cable Distance

Cable Catagory Speed
UTP 3 16Mbps
UTP 5 16Mbps
STP 5 16Mbps
UTP 3 4Mbps
UTP 5 4Mbps
STP 5 4Mbps
*Distances as tested with IBM Token Ring and SMC Token Elite Cards. Other cards guaranteed to
100 meters per 802.5 specification.
USER/S GUIDE
Max-Lobe Length* Max-RI\RO Length*
100 meters 150 meters
300 meters 300 meters
400 meters 400 meters
300 meters 300 meters
500 meters 500 meters
500 meters 500 meters
A A P P P P E E N N D D I I X X
C-1
