Insert RI LED
not illuminated and
RI connected to
active hub RO port
Normal RO LED
not illuminated and
RO connected to
active hub RI port
Lobe Port LED
not illuminated
The active hub's
RO port may be
configured as
passive.
The active hub's
RI port may be
configured as
passive.
Cable failure
(open/short).
Incorrect RJ45 cable
installed.
Invalid cable pin-
outs.
Workstation or
server NIC failure.
Lobe port connector
failure.
Switch RO to "P"
(passive) position.
Switch RI to "P"
(passive) position.
Check cable assembly or
tester or swap cable with
known good cable.
See 3.5.2 for pin
specifications
See 3.5.2 for cable
pin-outs
Check NIC
configuration/setup with
manufacturer.
Contact TN Technical
Support.
1-800-260-1312.
StackMaster™TR
