Resetting the StackMaster™TR 16-Port

Transferring the File

USER'S GUIDE
Reset the StackMaster™TR 16-Port in any of the following ways:.
• Disconnect power cord to SNMP Management Unit or to
StackMaster™TR 16-Port Unit with installed SNMP management
board, then reconnect the power cord.
• Press the reset button on the SNMP Management Unit or
StackMaster™TR 16-Port Unit with installed SNMP management
board.
• At the attached terminal or terminal emulation, type and enter:
Ready to RECEIVE file using XMODEM/crc/binary/xon/xoff.
Initiate SEND from host . . .
Stop
ANY MENU >
ANY MENU >
At power on or reset, the Status LEDs cycle through diagnostic test
patterns as internal StackMaster™TR 16-Port software tests: Flash, serial
port, dynamic RAM, static RAM, dual port memory, and each of the
Ethernet ports.
After the diagnostic test patterns, for twenty seconds, the Status LEDs
display a pattern in which four LEDs remain illuminated while four LEDs
flash continuously. This pattern indicates that the StackMaster™TR 16-Port
software is waiting for an optional user interrupt.
To transfer the file:
1. Determine the exact drive and path to the updated .BIN file.
NOTE: Step 2 must be completed during the twenty-second period that
the Status LEDs display the optional user interrupt pattern.
5 5 . . M M A A I I N N T T E E N N A A N N C C E E
Sending
restart
quit
5-11
