Unit "freezes".
Cannot manage
stack
Table 5-1. Fault Isolation in the StackMaster™TR 16-Port Stack
5 5 . . M M A A I I N N T T E E N N A A N N C C E E
RI, RO switches are
in passive position
but one port is not
connected.
ZDL disabled and
wrong speed station
tries to insert.
RI or RO cable
broken while in
"Passive" position.
Stack initialization
Incorrect
management cable
used.
Set unconnected port
switch to "A"(active)
position.
Switch ZDL to ON
and reset hub.
Replace cable.
Reset Stack (See 5.2
Replace cable.
