Indicators
1-4

Power LED

16 Port StackMaster TR ™
Active Retiming Managed Hub
Insert
T R A N S I T I O N
P
4 Mbps
n e t w o r k s
Power
Reset
16 Mbps A Ring In
Power
When the StackMaster™TR 16-Port Unit is powered, the Power indicator
is illuminated.
Insert
16 Port StackMaster TR ™ Active Retiming Managed Hub
Insert
T R A N S I T I O N
P
4 Mbps
n e t w o r k s
Power
Reset
16 Mbps A Ring In
Insert/Normal LEDs
The Insert LED (above the Ring In port) is illuminated if the
StackMaster™TR 16-Port RI port is connected to the RO port of a hub.
NOTE: When the RI switch is in the passive position, the LED always is
ON, indicating that the RI port is configured in the passive mode.
The Normal LED (above the Ring Out port) is illuminated if the
StackMaster™TR 16-Port RO port is connected to the RI port of a hub
which is powered.
NOTE: When the RO switch is in the passive position, the LED always is
ON, indicating that the RO port is configured in the passive mode.
Normal
1 2 3 4 5 6 7
P
Ring Out
A
Normal
Normal
1 2 3 4 5 6 7
P
Ring Out
A
Lobe Ports
8 9 10 11 12 13 14 15 16
Lobe Ports
8 9 10 11 12 13 14 15 16
StackMaster™TR
Expansion Card
Indicators
Status
Enable
OFF 1 2 3 4
ON 5 6 7 8
ZDL
Expansion Card
Indicators
Enable Status
1 2 3 4
OFF
ON
5 6 7 8
ZDL
