A.3.5 Configuration Connector
RJ45 CONFIGURATION
A.4 Technical Specifications
Hardware Architecture
PROCESSORS
MEMORY
STORAGE UNIT
LAN Interface
PROTOCOLS
SPEED
CONNECTOR
DSL Interface
STANDARDS
SPEED
CONNECTOR
Wireless LAN Interface
STANDARDS
SPEED
CONNECTOR
USB Interface
3G USB MODEMS
SPEED
CONNECTOR
Teldat C1+L Router
RJ45 PIN
1
2
3
4
5
6
7
8
Broadcom BCM6358
64 Mbytes in SDRAM
FLASH Memory (16 Mbytes)
Ethernet (802.3)
SWITCH 10/100 Mbps (BaseT)
RJ45 female
Please see the manual on DSL
Please see the manual on DSL
RJ11 female
Please see the manual on Wireless LAN
Please see the manual on Wireless LAN
2 RF SMA Female
Please consult the Teldat webpage http://www.teldat.com to obtain the list of sup-
ported 3G USB modems.
The interface complies with the USB 2.0 standard (480 Mbps); the final speed de-
pends on the 3G USB modem used.
USB Type A
CONF
--
RxD
GND
--
--
GND
TxD
--
