1 Specification

Span*
Display Units
Averaging
Accuracy
Outputs
Inputs
Serial Port
Path Length
Flue Gas Temperature
Construction
Transmitter
Detector
Ambient Temperature Limits
Power Requirements
Air Purge Consumption
Issue: A Revision: 1 Date: 24/07/19
selectable from 0-100ppm to 0-10,000ppm, within
the range 200 to 6,000ppm. metres at STP
Ppm
mg/m
four averages selectable from 10 seconds to 30 days
± 2% of measurement or
± 5ppm whichever is greater
Analogue 4-20mA isolated,
High alarm Volt-free contact, 10A @ 250V
Data valid Volt-free contact, 10A @ 250V
Oxygen 4-20mA
Temperature 4-20mA
Pressure 4-20mA
Plant status Contact Volt free contact
for remote instrument operation,
normalising inputs and outputs
0.5 to 8m
0 to 650°C
cast aluminium, fully sealed to IP65
electrically heated silicon nitride cylinder
lithium tantalite pyro-electric detector
o
-20 C to 70
85-132/170-264V AC, 50/60 Hz, 50VA
1 litre/sec @ 1bar (compressed air)
5 litre/sec (blower air)
Ref: 100606
Section 1
3 3
(measured) mg/Nm (normalised)
500Ω max
o
C
Specification
Page: 11
