CODEL TunnelTech 500 Series Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TunnelTech-700
CODEL
Operating-and-Maintenance-Manual
Monitoring Solutions
CODEL
TunnelTech 500/700
Series
Display Interface Manual
For all TunnelTech 500, 510, 700 and 710 series
Tunnel Atmosphere Monitoring Systems
(CO/NO/NO
/Vis)
2
Unit 4, Station Road, Bakewell, Derbyshire DE45 1GE United Kingdom
t : +44 (0) 1629 814 351
f : +44 (0) 8700 566 307
e : codel@codel.co.uk
web : www.codel.co.uk
Issue: A
Revision: 7
Date: 04/11/20
Ref: 100577

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TunnelTech 500 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CODEL TunnelTech 500 Series

Summary of Contents for CODEL TunnelTech 500 Series

  • Page 1 (CO/NO/NO /Vis) Unit 4, Station Road, Bakewell, Derbyshire DE45 1GE United Kingdom t : +44 (0) 1629 814 351 f : +44 (0) 8700 566 307 e : codel@codel.co.uk web : www.codel.co.uk Issue: A Revision: 7 Date: 04/11/20 Ref: 100577...
  • Page 2 TunnelTech-700 CODEL Display Interface Manual Monitoring Solutions Issue: A Revision: 7 Date: 04/11/20 Ref: 100577...
  • Page 3 Operating-and-Maintenance-Manual Monitoring Solutions CODEL International Ltd is a UK company based in the heart of the Peak District National Park at Bakewell, Derbyshire. The company specialises in the design and manufacture of high-technology instrumentation for the monitoring of combustion processes and atmospheric pollutant emissions.
  • Page 4 TunnelTech-700 CODEL Display Interface Manual Monitoring Solutions Issue: A Revision: 7 Date: 04/11/20 Ref: 100577...

  • Page 5: Table Of Contents

    TunnelTech-700 CODEL Operating-and-Maintenance-Manual Monitoring Solutions Contents INTRODUCTION ............................9 ..........................9 EYPAD EMBRANE ..........................10 ELCOME CREEN 1.2.1 Fault Messages: .......................... 10 MAIN MENU ............................11 2.1.1 Measurements: ........................... 11 2.1.2 Diagnostics: ..........................11 2.1.3 Setup Mode: ..........................11 ........................12...
  • Page 6 TunnelTech-700 CODEL Display Interface Manual Monitoring Solutions 5.8.1 mA Species: ..........................36 5.8.2 mA Zero: ............................36 5.8.3 mA Span: ............................. 37 5.8.4 DAC Zero: ............................ 38 5.8.5 DAC Span:............................ 38 5.8.6 Simulate mA: ..........................39 ............................ 40 ELAY UTPUT 5.9.1...
  • Page 7 TunnelTech-700 CODEL Operating-and-Maintenance-Manual Monitoring Solutions IMPORTANT The warning signs (and meanings) shown below, are used throughout these instructions and are intended to ensure your safety while carrying out installation, operation and maintenance procedures. Please read these instructions fully before proceeding.
  • Page 8 TunnelTech-700 CODEL Display Interface Manual Monitoring Solutions Issue: A Revision: 7 Date: 04/11/20 Ref: 100577...

  • Page 9: Introduction

    Section_1 Introduction 1 Introduction This document is a user manual for the LCD interface for instrument TunnelTech 500/700, which helps to navigate the menus and sub menus using the unit’s keypad membrane. Keypad Membrane Using the keypad buttons the user can access and navigate the menus and sub NOTE: menus.

  • Page 10: Welcome Screen

    Display Interface Manual Monitoring Solutions Welcome Screen The welcome screen displays “Codel – FM” (manufacturer’s name) and “TT500/700 SERIES” (instrument’s name). The welcome screen is closely followed by the measurement initialisation screen. Depending on if the attached peripherals have been powered down, the current state of the attached devices will be displayed.

  • Page 11: Main Menu

    Section_2 Main Menu 2 Main Menu The Instrument has following main menu options: 2.1.1 Measurements: Acts as main screen for data observation and allows the user to select which measurand data is to be displayed. 2.1.2 Diagnostics: Allows the user to view more in-depth diagnostic data for each channel available on the device, as well as set some status information for peripheral measurement devices.

  • Page 12: Menu And Submenu Tree

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions Menu and Submenu Tree The table below illustrates the main program of the instrument. When an operating mode is complex, an extra program tree is given in this section. press to scroll through the menu.

  • Page 13: Measurements

    Section_3 Measurements 3 Measurements The measurements screen acts as the main observation screen, displaying the data collected from the attached peripherals. From the main measurements screen pressing button brings up the channel selection menu which allows the user to select which attached channel should be displayed on the main screen.

  • Page 14: Diagnostics

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions 4 Diagnostics The diagnostics menu allows the user to view general diagnostic information about each active channel in addition to the status flags for the attached device. Using the arrow navigation buttons, the user can navigate through the different channels, and peripheral board status menu options that are enabled.

  • Page 15: Diagnostics Channel Selection

    Section_4 Diagnostics Diagnostics Channel Selection Selecting the diagnostics menu should display a menu screen similar to the following (dependent upon the measurands of the device version): Using to navigate through the other measurands available on the device. Pressing the key will open the Diagnostic data submenu for the for currently displayed measurand.
  • Page 16 TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions The submenu data categories measured are the same for all gas species the E-Cell measures. If a channel related to the Vis is selected using the key, the following diagnostic data is returned:...

  • Page 17: Diagnostics Status Selection

    Section_4 Diagnostics Diagnostics Status Selection Sub Menu Tier 1 Sub menu Tier 2 Status E-Cell Mode Status (if available) Performance Status Status VIS Mode Status (if enabled) Performance Status The diagnostic status menu system can provide for the user, a constant update on the peripheral flags which describe the current condition the device is in.

  • Page 18: E-Cell Status Flags

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions E-Cell Status flags 4.4.1 Mode Status: Maintenance Mode - Determines if the maintenance flag has been set on the E-cell Span Calibration - Determines if a span calibration is currently in progress...

  • Page 19: Visibility Status Flags

    Section_4 Diagnostics Visibility Status flags 4.5.1 Mode Status: Maintenance Mode - Determines if the maintenance flag has been set on the Vis Span Calibration - Determines if a span calibration is currently in progress Post Calibration - Post calibration timer to allow the measurand to settle Pre-Calibration - Pre-calibration timer to allow operator to...

  • Page 20: Setup Mode

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions 5 Setup Mode PassCode Security When trying to enter the setup menu on the display device, the display will prompt for a security PassCode to be entered. Entering this menu using the key the user will be instructed to enter the PassCode.

  • Page 21: Setup Mode Submenu Tree

    Section_5 Setup Mode Setup Mode Submenu Tree press to scroll through the menu. Press to access a selected menu item Press on Exit option or Enter on the final option Press to return to the main measurements screen Main Menu Sub Menu Tier 1 Sub menu Tier 2 Sub menu Tier 3...
  • Page 22 TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions Main Menu Sub Menu Tier 1 Sub menu Tier 2 Sub menu Tier 3 Measurements Parameters Comms (B,D,P,S) Diagnostics Protocols Setup Mode Comms Address Maintenance Due (only shown while the E-Cell is enabled)

  • Page 23: Module Selection

    Section_5 Setup Mode Module Selection Sub Menu Tier 1 Sub menu Tier 2 Module Selection EC Board Enable Vis Board Enable AN1 Board Enable AN2 Board Enable Exit The Module selection menu allows the user to enable or disable attached peripherals.

  • Page 24: Running Mode

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions Running Mode Sub Menu Tier 1 Sub menu Tier 2 Running Mode EC Running Mode (if enabled) VIS Running Mode (if enabled) Exit The Running mode selection menu allows the user to select between the “Normal”...

  • Page 25: Zero Calibration

    Section_5 Setup Mode Zero Calibration Sub Menu Tier 1 Sub menu Tier 2 Zero Calibration Full Zero Calibration Exit The Zero calibration menu is designed to zero calibrate all attached peripherals connected to the display unit within one menu item. Entering the “Zero Calibration”...

  • Page 26: Sensor Setup Menu

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions Sensor Setup Menu Sub Menu Tier 1 Sub menu Tier 2 Sub menu Tier 3 Sensor Setup Configure CH1 Span Range (if enabled) Calibrate Exit Configure CH2 Cell Range (if enabled) Calibrate...

  • Page 27: Cell Range: (E-Cell)

    Section_5 Setup Mode When entering the Sensor Setup menu, the first available channel is displayed. If the device being read is the Electrochemical cell board the menu will display the current measurand that the device is set to. Alternatively, if only the Visibility board is attached the menu heading will simply display “VIS”.

  • Page 28: Span Factor

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions 5.6.2 Span Factor: For each of the attached channels the menu system allows the user to set the span factor, the decimal place signifies a thousand so 01.000 gives a span factor of 1,000.

  • Page 29: Span Offset

    Section_5 Setup Mode 5.6.3 Span Offset: For each of the attached channels the menu system allows the user to set the span offset. To configure the span offset, press the key to enter the “Set Span Offset” menu Using the keys, the user can adjust the currently selected digit ranging from 0 to 9, exceeding these ranges automatically rolls the figure to the opposite end of the scale.

  • Page 30: Calibration

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions 5.6.4 Calibration: The calibration menu allows the user to perform both a zero calibration for each of the channels available to the device. To perform a calibration, press the key to enter the “Initiate Cal” submenu From this menu a calibration can be performed.
  • Page 31 Section_5 Setup Mode When these menu items are selected, using the key, the user is presented with the Adjust Gains screen, where the user can set the Tx or Rx gain values from 0 - 255. using the key, use the keys, to adjust the currently selected NOTE: digit ranging from 0 to 9.

  • Page 32: Parameters Menu

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions Parameters Menu Submenu 2 Submenu 3 Parameters Comms (B,D,P,S) Protocols Comms Address Maintenance Due (only shown while the E-Cell is enabled) Exit The Parameters menu displays useful information relating to the communication and maintenance of the system.

  • Page 33: Protocols

    Use with caution Using the keys, the user can toggle between the Codel Protocol and Modbus Protocol. To set the protocol simple press the key on the desired protocol. This configurable menu allows the user to change the device address external serial 5.7.3...

  • Page 34: Maintenance Alarm

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions 5.7.4 Maintenance Alarm: The maintenance due date is an alarm hardcoded into the E-Cell board. When the date elapses the alarm LED illuminates to warn the user that the E-Cells are due to be replaced.

  • Page 35: Ma Output

    Section_5 Setup Mode mA Output Submenu 2 Submenu 3 Submenu 4 mA Output AN1 – CH1 Species (if enabled) Zero Span DAC Zero DAC Span Simulation Exit AN1 – CH2 Species (if enabled) Zero Span DAC Zero DAC Span Simulation Exit AN2 –...

  • Page 36: Ma Species

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions The mA output menu allows the user to configure the measurand, zero and span information for the attached mA boards. In addition, the menu allows the user to simulate a given value on any attached board to test each individual channel.

  • Page 37: Ma Span

    Section_5 Setup Mode By pressing the key, the user can adjust the current value for the selected mA channel. Using the keys, manipulates the currently selected digit between 0-9, with the key moving to the next available location or setting the entered value to the device once all 5 fields are complete. 5.8.3 mA Span: When setting the Span value on the mA board, the menu system uses the...

  • Page 38: Dac Zero

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions 5.8.4 DAC Zero: The DAC (Digital Analog Converter) Zero and Span menus allow the user to adjust the Zero position and Span range for each milliamp output, allowing micro adjustments to be made to the value to increase the accuracy of said outputs.

  • Page 39: Simulate Ma

    Section_5 Setup Mode 5.8.6 Simulate mA: The TT500/700 has the ability to simulate an mA output. This menu is useful for testing the calibration of any connected system. When entering the simulation menu, the user is presented with the base calibration output of 12 mA.

  • Page 40: Relay Output

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions Relay Output Submenu 2 Submenu 3 Submenu 4 mA Output AN1 – CH1 Relay Trigger (if enabled) Direction Level Exit AN1 – CH2 Relay Trigger (if enabled) Direction Level Exit AN2 – CH3...

  • Page 41: Relay Trigger

    Section_5 Setup Mode 5.9.1 Relay Trigger: The first menu accessible Is the measurand selection menu, this menu displays the measurand on which the alarm should trigger. Each channel can independently trigger on any measurand with different trigger levels selected. WARNING: If the measurand is set to a measurand location that is not Internally the system has 6 set measurands:...

  • Page 42: Relay Direction

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions 5.9.2 Relay Direction: The relay system allows the user to configure if the relay channel is set to normally open or normally closed. This option is useful in fail-safe environments where power outages are common, forcing the connected relays to switch in case of power failure.

  • Page 43: Rtcc Setup Mode

    Section_5 Setup Mode RTCC Setup mode Submenu 1 Submenu 2 RTCC Time Date Exit The TunnelTech 500 and TunnelTech 700 contain a real-time clock and calendar. Allowing the system to keep up to date with maintenance. On entering the RTCC setup menu, the user is presented with the device’s current time, Pressing the keys, allows the user to cycle between the time...

  • Page 44: Passcode

    TunnelTech 500/700 CODEL Display Interface Manual Monitoring Solutions Pressing the keys, allows the user to adjust all fields within the set time menu with the key moving to the next field if all the time fields have been filled, the RTCC menu processes the full time date packet.
