5.8
5.8.1

Display Format

Issue: A Revision: 1 Date: 24/07/19

Normalisation

Press the MODE key until the number 3 is seen in the top left corner of the
display. From this mode, the normalisation parameters currently being used can
be displayed. Press the ENTER key to enter the routine and use the ARROW keys
to select which of the normalising parameters to display.
When the required normalising parameter is displayed, press the ENTER key to
display the normalisation data. Press the ENTER key again to exit the parameter.
For each of the normalising parameters the display will appear similar to that
shown below.
Selected parameter
Standard level required
(wet or dry for water vapour)
Ref: 100606
Section 5
Normal Operation
Units
Parameter source:
k – keypad input
a – analogue input
s – serial data input
