EnergyTech 401
Operating and Maintenance Manual
5.9
Figure 18 : Diagnostic Mode Tree
Page: 80

Diagnostic Mode

The detector levels, chopper blade frequency, 'Y' parameter and the fault
condition may be examined from this mode. Press the MODE key until number 4
appears in the top left corner of the display and press ENTER to enter the mode.
The ARROW keys will now select from the following list; press the ENTER key to
select the displayed option.
Press Enter on Exit option
Detector Outputs
Mod. Frequency
Y Values & ppm
Water Vapour
Calibration Data
Fault C ondition
CODEL
Monitoring Solutions
Enter

Detector levels

D1, D 2, E1, E2,
d1, d2, e1 & e2
Saturati on count &
phase correction
Modulation frequency
of detector D1
Modulation frequency
of detector D2
Parameter Y values
Instantaneous gas
calculation (ppm)
H2O%.m & X value
(1030 only)
Cal values
Rx temperature
Fault status
