5.5
Figure 17 : Program Operation Tree
Issue: A Revision: 1 Date: 24/07/19

Program Tree

Figure 17 illustrates the main program of the instrument. When an operating
mode is complex, an extra program tree is given in this section.
Press Enter on Exit option or
Enter on the final option
Operating Mode - 1
Mode
Parameter Mode - 2
Mode
Normalisation Mode - 3
Mode
Diagnostic Mode - 4
Mode
Set-Up Mode - 5
(accessed after entering
a security code)
Mode
Check Cell Mode - 6
Modes 1-4 change the display only
Ref: 100606
Section 5
Normal Operation
Enter
Concentrati on units
Measured or normalised
Averaging time
Indentification
Parameters
Averages
Output
Alarm source & level
Plant status
Auto zero (1021 only)
Temperature
Oxygen
Pressure
Water vapour
Detector levels
Modulation frequencies
Y & Z values
H2O%.m (1030 only)
Cal. values
Fault condition
Set averages
Configure O/P
Parameters
Normali sation
Reset average
Cali brate
Check cell gas ppm
