3 Specification

3.1 Sensor

Sensor type
Measurement
Standard measurement range
Calibration
Operational Temperature
Electrical connection requirements
Signal output
Output signal cable
Power consumption
Accuracy
AC dielectric test
Impulse dielectric test
Issue: A
Page 3
Silicon Photocell with eye response filter. 20° viewing
angle
cd/m².
0-6500 cd/m². (max range 0-10000 cd/m² available on
request)
Tracible to British National Physics Laboratory
NPL Ref. 2009080077/594/59.
-20°C to 60°C. Dual heater available on request -40°C to
60°C
±1° within 50°C from the 25°C calibration temperature
230VAC 50/60Hz
115VAC 50/60Hz
24VAC 50/60Hz
24VDC. Range 10 to 35V
4 – 20mA sourced. External termination 100 – 800 ohms
0 – 20mA sourced.
0 – 5V sourced
Belden type 8771 (or similar) with conductor resistance of
less than 10 Ω/km is recommended
20VA including internal thermostatically controlled heater
±3%
2KV 50Hz for 1 minute
5KV 1.2/50 microseconds
