Alarm Screen
Description &
Classification
Dirty Filter
Dirty filter
switch is
detected
*Warning
Humidity
Humidity
Sensor
Sensor failure
*Warning
Custom
Custom Alarm
message
*Warning
Clock Board
Clock may not
Fault or Not
function when
Connected
power is off
*Warning
Unit in Standby
Optional Alarm
switch set to
put unit in
(This is a not
an actual
Possible Causes
inhibits humidification
if any unit has recently
been dehumidifying
Dirty filter (detected by
tan mounted pressure
differential switch)
Calibrate differential
switch
Faulty Sensor
Loose Connection
Incorrect settings on
the controller
Loose sensor
Faulty sensor
Check connections for
polarity
Incorrect settings on
the controller
The indicated Custom
Alarm input has not
been assigned a
custom message or
given a name
Battery could be bad
or not re-charging
Optional Alarm switch
connected to DARA4
controller if installed
108
Corrective Actions
Check zone master settings and
temperature/humidity set points
of all units
Change Filter
Adjust differential pressure set
point of switch
Replace differential pressure
switch if needed
Check Connection and cable
Go to Menu L- Configure I/O and
change the Dirty Filter Switch
action setting
Check connection
Use sensor chart to check
sensor signal (in milliamps).
Replace sensor if required
Connect wiring to correct
connection points
Go to Menu L- Configure I/O and
check the Humidity Sensor
(U01) settings
Check this alarm switch setting
and assign it a name or custom
message
Replace battery (please contact
factory) for help.
Check DARA-4 wiring to units
and configuration
