Hex/Ascii Display Change - Omron SYSMAC C2000H Operation Manual

Monitoring Operation and Modifying Data
Key Sequence
Example
7-2-4

Hex/ASCII Display Change

Key Sequence
258
Word currently
monitored on
left of display.
The following example shows the effects of changing the PV of a timer.
This example is in MONITOR mode
This operation converts DM data displays back and forth between 4-digit
hexadecimal data and ASCII.
Word currently
displayed.
[ Data ]
Section 7-2
Timing
PV changed
Timing
Timing
Timing
