3-5-1 Sysmac Link System Data Link Settings; 3-5-2 Active Node Flags - Omron SYSMAC C2000H Operation Manual

AR Area
Word(s) Bit(s)
24 00 to 03
04 and 05
06
07
08 to 10
11
12
13
14
15
25 00 to 15
26 00 to 15
27 00 to 15

3-5-1 SYSMAC LINK System Data Link Settings

External/Automatic Allocation
Words per Node

3-5-2 Active Node Flags

Leftmost digit of FALS-generating address
(AR 25 contains the other four digits)
Not used and not accessible by user.
Level 1 Network Parameter Flag
Level 0 Network Parameter Flag
Not used and not accessible by user.
PC Link Unit Level 1 Mounted Flag
PC Link Unit Level 0 or Single-level PC Link Unit Mounted Flag
SYSMAC NET Link Unit Mounted Flag
Rack-mounting Host Link Unit Mounted Flag
CPU-mounting Device Flag
Rightmost four digits of FALS-generating address
(AR 2400 to AR 2403 contain the fifth digit)
Maximum cycle time
Present cycle time
AR 0700 to AR 0703 and AR 0704 to AR 0707 are used to designate word
allocations for operating levels 0 and 1 of the SYSMAC LINK System. Alloca-
tion can be set to occur either according to settings from a Peripheral Device
(e.g., FIT) or automatically in the LR and/or DM areas. If automatic allocation
is designated, the number of words to be allocated to each node is also des-
ignated. These settings are shown below.
Operating level 0
AR 0700 AR 0701
0 0
1 0
0 1
1 1
The following setting is necessary if automatic allocation is designated
above.
Operating level 0
AR 0702 AR 0703
0 0
1 0
0 1
1 1
The above settings are read every cycle while the SYSMAC LINK System is
in operation.
AR 08 through AR 11 and AR 12 through AR 15 provide flags that indicate
which nodes are active in the SYSMAC LINK System at the current time.
Function
Operating level 1
AR 0704 AR 0705
0 0 Words set externally (e.g., FIT)
1 0 Automatic
0 1 allocation
1 1
Operating level 1 words per node
AR 0706 AR 0707 LR area
0 0 4
1 0 8
0 1 16
1 1 32
Section 3-5
Setting
LR area only
DM area only
LR and DM
areas
Max. no.
DM area of nodes
8 16
16 8
32 4
64 2
