The following figure shows the connectors used for the DE power option.
As noted in the previous figure, although you can supply the control and drive power from one power
supply, you will only get the full benefits and maximum protection by using separate power supplies.

IP65 and IP67 M-Style Motors

Certain models of M-style SmartMotors are available in IP-rated versions (see the Moog Animatics
Product Catalog for details). The standard IP rating is IP65, which protects the motor from dust
particles and splashing water. Additionally, certain motors can be ordered with the higher IP67 rating.
Contact Moog Animatics for details.
IP ratings are in accordance with the code defined in international standard IEC 60529. Instead of the
vague descriptions of "waterproof", "water-resistant" or "dustproof", the IP-rating system provides a
uniform, quantifiable set of standards to which each product is rigorously tested. The IP code refers to
the degree of protection for the electrical enclosures on a machine against liquid, solid objects and
particulates. The first number following "IP" refers to the level of protection of the hazardous parts
and electrical enclosures against solid objects and particulates, and the second digit indicates the
level of water resistance. The higher the first digit rating in the IP system, the smaller the foreign
object that it is protected against.
SmartMotors with the IP65 rating are both completely dust tight and protected from ingress of liquid
that may occur from any angle (see CAUTION statement above), rendering no harmful effects on the
electrical enclosure. SmartMotors with the IP67 rating can be submersed in water or other non-
hazardous liquids to a depth of one meter for a maximum time of 30 minutes. Therefore, conditions
with high levels of humidity and condensation are no longer a problem. The IP-rated models provide
the perfect integrated servo for food and beverage manufacturing and packaging, rugged outdoor
conditions, as well as any wet environment.
Moog Animatics Class 5 SmartMotor™ Installation and Startup Guide, Rev. I

IP65 and IP67 M-Style Motors

D-Style SmartMotor Showing DE Power Option
Page 22 of 76
Control power supplied to this
connector (20-48 VDC)
Drive Amp power supplied to
this connector (20-48 VDC)
NOTE: The same power supply may be
used for Control and Drive power, but
maximum protection is provided with
separate power supplies.
