8 To remove a single screenshot, see the screenshot fullscreen, press on
option menu
4.5

Datalogger

Description
►
Datalogger function can logger automatically several measurements depending
on the selected function, including signal level and channel power, carrier/noise,
BER and MER for all channels in a specific channel band.
Operation
►
1 To start datalogger, press on DATALOGGER at the left lower corner inside the
tool. You can also press on "Test & Go" green button at the home screen.
2 A window opens with several setting options. You can edit boxes with colour
background (name, location, threshold...) when pressing on it. Check the
box to select measurements and press on "Start Measuring" or "Cancel".
3 It starts datalogger.
4 After finish, press on "Save and close", "Save and go to datalogger" or
"Cancel".
Chapter 4: TOOLS
and then on "Remove" and confirm.
Figure 37.
61 March 2020
