Datalogger - Test & Go - Promax RANGER mini User Manual

8 To remove a single screenshot, see the screenshot fullscreen, press on
option menu
4.3 Datalogger - Test & Go
Description
►
Datalogger function can made and save automatically several measurements
depending on the selected function, including signal level and channel power,
carrier/noise, BER and MER for all channels in a specific channel band.
The Test & Go function is a shortcut in the home screen that starts a datalogger
set by default in the Test&Go configuration option.
Operation
►
1 To start datalogger, select a function and press on DATALOGGER at the left
lower corner screen.
2 You can also press on "Test & Go" at the home screen. In this case you must
select the datalogger by default through the option Test&Go configuration
from the settings menu in the main screen.
September 2018
and then on "Remove" and confirm.
Figure 23.
38 Chapter 4: TOOLS
