2 Constellation Diagram and measurements for the channel pointed by the
marker.
Options Menu
►
There are some options at the bottom of the screen:
: Screenshot.
DATALOGGER: It creates a datalogger with measurement data.
SPECTRUM: It returns to the DOCSIS DOWNSTREAM SPECTRUM
ANALYZER function (see previous section).
RANGING: (only for CABLE) It enables the RANGING function (see next
section).
CLR IQ: It clears Constellation Diagram.
Settings
►
Click on the MENU
The DOCSIS BONDING GROUP function has these options:
Edit channel plan: It allows you to edit a channel plan and DBG (refer to
"Edit Channel Plan" chapter).
CM Information: It shows information about software and MAC address
of CableModem.
Power at CMTS: It sets minimum level power to receive from the CMTS
(Cable Modem Termination System)
3.5.3 CABLE MODEM SCAN (cable & FO)
Description
►
The SCAN CM function shows on screen the signal level in graphic bar format
for each one of the active channels for the cablemodem band.
Chapter 3: MEASUREMENT
