►Settings
Parameter
Trace
Upstream band
Channel bandwidth
6.7 Input Voltage and RF Power Meter
►RF Power Measurement
Parameter
Frequency band
Power accuracy:
►Input Voltage Measurement
Parameter
VDC
VAC
Frequency measurements
►Configuration Menu
Parameter
Units
6.8 Optical Measurement
►Optical Power Meter
Parameter
Optical Band
Connector
Dynamic range
Calibrated wavelength
Chapter 6: SPECIFICATIONS
Value
Max hold and min hold
Docsis 2.0 upstream band/ Docsis 3.0
upstream band
CW, 5 MHz, 7 MHz or selectable
Value
5-1700 MHz
± 3 dB
Value
1-90 V
1-30 V,
From 10 Hz to 200 Hz,
Value
dBmV, dBuV, dBm
Value
1100 nm – 1700 nm
SC-APC
- 50dBm to 10 dBm (0.5 dB
accuracy)
1310, 1490, 1550, 1625 nm
77
Datos Adicionales
Additional Data
Additional Data
±2 % accuracy
Additional Data
Additional Data
March 2020
