Promax Cable Ranger+ User Manual page 30

Description of Signal Demodulation Screen
►
1 Demodulated Signal.
2 Measurement obtained from signal demodulation (for more details refer to
"Demodulator" on page
Options Menu
►
There are some options at the bottom of the screen:
: Screenshot.
CLEAR: It clears spectrum trace (this options is available if trace was hold
previously).
CLR IQ: It clears the signal constellation.
: It comes back to the main screen.
Settings
►
Click on the MENU icon
menu. The SATELLITE function has these options:
Chapter 3: MEASUREMENT
Figura 14.
56).
at the upper right corner to access the Settings
25 March 2020
