Channel Plan Editor Operation
►
1
Files with channel plans are inside the "ChannelPlans" folder. Select the file
that contains the channel plan to edit and press the right button on the
mouse to select the "Edit channel plan" option.
2
The channel plan definition parameters and all the channels that form it will
appear. From here you can edit any value by clicking on the box.
3
Channels can be modified by clicking on each parameter.
4
Once the channel plan is finished, click on "Download Channel Plan" to
download it to the PC. By default the file with the channel plan is downloaded
in the PC "Download" folder. The file is in XML format.
5
To use the channel plan, upload the XML file by means of the File Manager
with the option "Upload files". Upload it to the "ChannelPlans" folder. The
channel plan should be now available to use it on the meter.
Chapter 5: WEBCONTROL
69
March 2020
