Promax Cable Ranger+ User Manual page 41

Upstream
UC: Upstream Channel.
F: Frequency (MHz).
PWR: Power (dBmV).
ATT: Channel attenuation (dB).
SR: Symbol Rate (ksymps).
Speed (bits/s).
IP Report
Cable Modem: IP for cable modem.
Gateway: Gateway IP.
Netmask.
DHCP Server: IP for DHCP server.
TFTP Server: IP for file transfer server.
Options Menu
►
There are some options at the bottom of the screen:
: Screenshot.
DATALOGGER: It creates a datalogger with measurement data.
BACK: It comes back to DS SPECTRUM screen.
IPTV: It opens TEST IPTV function (see next section).
VoIP: It opens TEST VoIP function (see next section).
SPEED: It opens TEST SPEED function (see next section).
Setting Menu
►
Click on the MENU
menu. The REGISTERING function has these options:
Units: It allows you to select the measurement unit for power (dBuV,
dBmV, dBm).
Att CM: It enables / disables Cable Modem attenuation.
March 2020
icon at the upper right corner to access the Settings
36 Chapter 3: MEASUREMENT
