Contact details: Full name, company name and address, phone number
and e-mail.
Internal number shown on the window.
Recovery code shown on the window.
2 Once this information is sent, it is checked and if everything is right, a
temporary password is sent back. Write this password on the box "temporary
password". This password is for one time use.
3 If you have access to the main screen go to "Config" on the upper right
corner and click on "Change Password".
4 A window will appear to change the password. Enter the temporary password
in the "Old password" box. Enter your new password in the "New password"
box and again in the "Repeat new password" box. Press OK.
5.3

File Management

Description
►
Installations Management allows you to access the File Manager and the Create
Channel Plan tool.
At the top of the screen there is some data about the meter connected (model
name, serial number, release/webControl version) and some user settings:
Change password, reboot equipment and logout.
To access this screen press on
5.3.1 File Manager
This function allows you to manage files inside an installation (channel plans,
screenshots, etc.).
File Manager Operation
►
1 Press on tab "File Manager" to access the file manager. Wait for few seconds
to system to read all files from the meter.
2 All files and folders are shown on the left side of the window. The
"ChannelPlans" folder contais channel plans. The "Screenshots" folder
contains screenshots. When clicking on a folder it deploys its content in a
tree structure. The area on the right side shows the content inside the
selected folder.
