3.5.6 IPTV (cable)
Description
►
The IPTV test function performs an analysis of quality parameters for this type
of service. The optimization of these parameters guarantees the best quality of
service. In addition, knowledge of network conditions is important to install and
fix other problems.
Screen Description
►
1 It allows you to enter the IP address where sending the test signal.
2 Node id: It shows the selected node.
3 It shows some parameters obtained from test:
IP address: IP address to test.
Latency: Delay due to transport or processing.
Jitter: Variation of latency over time.
PLR (Packet Loss Rate): Percentage of lost packets over total sent
packets.
4 Send / Stop: It starts / stop the IPTV test .
5 Graph with intermediate nodes and time (ms) for the test signal.
Chapter 3: MEASUREMENT
Figure 20.
