You can configure the public LAN connection (LAN 1) using one of the following
methods:
• Use Dynamic Host Control Protocol (DHCP) to assign the HAFM appliance
IP address, subnet mask, and default gateway IP address. You can either
auto-detect or manually select the DNS server IP address.
• Manually enter the HAFM appliance IP address, subnet mask, default gateway
IP address, and DNS server IP address.

Configuring public LAN addresses using DHCP

To configure TCP/IP network information for the private LAN connection (LAN 1):
NOTE:
Before starting this procedure, ensure that the LAN 1 interface is physically connected
to the LAN. An LCD display of 0.0.0.0 indicates a physical LAN connection is not
present.
At the LCD panel, press ENTER. The Welcome!! or operational information
1.
message changes to the following
Figure 16 LCD panel (Input Password)
2. Using the
the
right, input the default password (9999), then press ENTER. The LAN 1
Setting?? message is displayed at the LCD panel.
Press ENTER and the following message is displayed
3.
the selection of DHCP.
Figure 17 LCD panel (DHCP selection)
Use the arrow keys as described in step 2 and select YES to use DHCP, then
4.
press ENTER. The following message is displayed
HP StorageWorks HA-Fabric Manager Appliance installation guide FW07.00.00/HAFM
button to increment a digit, the
button to move the cursor left, and the
(Figure 16):
button to decrement a digit,
button to move the cursor
(Figure
(Figure
17) to allow
18):
