Configuring Public Lan Addresses; Lcd Panel (Input Password) - HP StorageWorks HA-Fabric Manager Installation Manual

Figure 13 LCD panel (Input Password)
2. Using the
the
right, input the default password (9999), then press ENTER. The LAN 1
Setting?? message is displayed at the LCD panel.
3. Press the
displayed at the LCD panel, then press ENTER. The following message is
displayed
Figure 14 LCD panel (New Password)
4. Use the arrow keys as described in step 2 to input a new 4-digit numeric
password, then press ENTER. The following message is displayed
Figure 15 LCD panel (Save Change)
5. Press ENTER. A Wait a moment!! message is displayed at the LCD panel,
the LCD panel returns to the LAN 1 Setting?? message, and the password
changes.
6. Press the up and down arrow keys until Return?? is displayed, then press
ENTER. The LCD panel returns to scrolling mode, which continually displays
HAFM appliance operational information.

Configuring public LAN addresses

NOTE:
Before starting this procedure, ensure that the LAN 1 interface is physically connected
to the LAN. An LCD display of 0.0.0.0 indicates a physical LAN connection is not
present.
32
Configuration
button to increment a digit, the
button to move the cursor left, and the
button several times until the Change Password? option is
(Figure 14):
button to decrement a digit,
button to move the cursor
(Figure 15):
