Mircom FX-2200 Series Programming Manual page 51

recommended rates are: 4800, 2400, and 1200. Below is a table documenting the
maximum wire capacitance allowed on a single port connection.
Baud Rate
9600
4800
2400
1200
• Port 3: These options are restricted to Privilege 2. The options available vary depending upon
the Port 3 setting in the database. This port can only be disabled from the database.
PC Connect: Allows for the configuration of the communications to a GRID package. If
more than one signal needs to be sent, new alarms take precedence.
-- Baud: Set the communications baud rate. The available fixed baud rates are 9600,
4800, 2400, 1200, 600 and 300.
-- Delay: Sets the length of time the panel will wait before reporting the GRID package off-
line. This can be set from 10 to 255 seconds.
-- Disconnect: If enabled, the Common Disconnect hot key will shut down Port 3. The
GRID package will report the panel as offline.
Only if the communications line cycles between on-line and off-line. (Range: 1 to 25)
• Terminal: Select ANSI or TeleVideo protocol. Most terminals and terminal emulator
programs support ANSI protocol.
• Port 6: Allows for the setting of the baud rate to RAM-2644LCD annunciators, the city tie
modules, and the UDACT-2200 dialer. The settings are 4800 and 1200. If none of these
devices are programmed in the database, the message "nothing to program" is shown.
Alarm List
This menu controls the operation of the Alarm List. This function is restricted to Privilege Level 2. It
has the following options:
• Reset: Select when entries are taken out of the Alarm List. AUTO removes entries as
soon as the condition restores. MANUAL requires that Reset be pressed before they are
removed. Conditions that have restored are shown as a restored condition in the Alarm
List.
• Remote: Routes the messages for events from the panel to annunciators. The options
are:
-- ALL: All messages are sent to all annunciators.
-- SELECT: Messages are sent as directed in the database.
Passcode
Allows for the changing of passcodes. The Privilege Level 2 can change both the Level 1 and 2
passcodes, while Level 1 can only change the Level 1 passcode. Passcodes are four digit
numbers in the range 1000 to 9999. Type in the new passcode and press <Enter> to accept.
Asterisks are displayed instead of the numbers. <Clear> removes any digits typed. If no digits are
displayed, <Clear> returns to the Program or Passcode Menu.
The default Level 2 passcode is 2222. The default Level 1 passcode is 1111. These passcodes
should be changed to prevent unauthorized access.
Maximum Capacitance
100 nF
220 nF
470 nF
680 nF
FX-2200 Programming Manual
45
