FX-2200 Programming Manual
broadcast to panel 3, but panel 3 will not pass the broadcast on to panel 5 since it is supposed to
be communicating to panel 4.

Figure 3: Panel Removed from Network

1.4 Addressable Devices

Supported Devices
The FX-2200 can use analog/addressable devices. There are two general types of devices:
sensors and modules. The following devices are supported:
Modules
Sensors
4
MIX-M500C Control module
MIX-M500X Isolator module
MIX-M500DM Dual Input Monitor Module
MIX-M500M Monitor module, Classes A/B initiating
MIX-M501M Mini Monitor module, Class B initiating
MIX-M502M Monitor Module for 2- wire smoke detectors
Classes A/B initiating
MIX-M500S Control module
MIX-M500R Relay Module
MIX-M500X Fault isolator module
MIX-1251 Ionization type smoke detector, low profile
MIX-2251 Photoelectric type smoke detector, low profile
MIX-2251T Photoelectric type smoke detector c/w heat
detector, low profile
MIX-2551TH Photoelectric type smoke detector c/w heat
detector
MIX-5251 Fixed temperature detector, low profile
MIX-5251R Rate of Rise and fixed temperature detector, low
profile
