FX-2200 Programming Manual
Key
Relay
Disconnect
Test Mode
Signal
Disconnect
Common
Disconnect
General
Alarm
Halt
Switch n On
Switch n Off
26
Action
Causes the function relays and control modules to ignore any new alarms. Press
again to restore normal operation. The red LED will flash while active. If no relays
nor control modules can be disconnected, Relay Disconnect will do nothing. This
function can be set to Privilege Level 0 or 1.
Places panel into test mode. Press again to return to normal mode. The red LED
will flash while in test mode. This function can be set to Privilege Level 0 or 1. It fol-
lows the Disconnect privilege level (set in MPI). During test mode, the remote
annunciator zone LEDs becomes non-latching for the zone(s) under test. The com-
mon indicators, bells, relays and releasers are not activated and no commands are
sent to other units and no signal is sent out of Port 3. Test signals can be archived
or not as required.
Before beginning testing, the circuits/devices to be tested must be selected. All
unselected circuits/devices will operate normally. Be sure that the panel is in test
mode. To select circuits/devices, select PROGRAM from the Main Menu on the
LCD. The arrow keys move the cursor and the <Enter> key selects the item. Then
select ADDRESSABLE, then TEST. Enter the device circuit and address for each
device to be tested. <Clear> will return to the previous menu.
When test mode is ended, all zones and devices selected for testing automatically
return to normal operation.
Note: There is no Ground Fault isolation while Test Mode is active.
Disables sounding of the bells. The buzzer beeps every 2 seconds while the bells
are disabled. This beeping is suppressed while a privileged level is entered in the
panel. Press Signal Disconnect again to re-enable the bells. The red LED will flash
while the bells are disabled. Signal Disconnect is not available if the bells are
already activated. This function can be set to Privilege Level 0 or 1.
Disables the municipal relays from functioning. Press again to enable relays. The
yellow LED flashes while the relays are disabled. The municipal relays affected are
programmable. If no relays are selected for disabling, Common Disconnect is
unavailable. This function can be set to Privilege Level 0 or 1.
Initiates the general evacuation sequence. All bells are activated in Evacuation
mode, selected function relays are activated and selected releaser circuits are acti-
vated and municipal alarm relay is activated. The yellow LED will flash when acti-
vated. Press System Reset to cancel the General Alarm. Note: General Alarm is
recorded in the panel archive.
Stops the operation of all releaser type outputs on the panel. The green LED
flashes when the key is available and the yellow LED flashes when it has been
pressed.
Change the state of the software switch n between Auto and On. The yellow LED
will flash while the switch is forced On. The green LED will flash whenever the
switch is on, either automatically or forced. Switches can affect relays, control mod-
ules and LEDs. This function can be set to Privilege Level 1 or 2.
Change the state of the software switch n between Auto and Off. The yellow LED
will flash while the switch is forced Off. The green LED will flash whenever the
switch is off, either automatically or forced. Switches can affect relays, control mod-
ules and LEDs. This function can be set to Privilege Level 1 or 2.
