FX-2200 Programming Manual
Pushbuttons
The following push buttons are defined:
•
•
•
•
•
•
•
•
•

2.6 Panel Window

Overview
The Panel Window (see Figure 8) allows editing of all panel level options. It defines the hardware
mounted in the panel and the functionality of the programmable outputs. The programming
controls provided change to reflect the capabilities of the currently selected panel. The Title Bar
describes the currently highlighted panel or annunciator.

Figure 8: Panel Window

16
Exit: Close the Groups Window and return to the previous window.
Add Group: This defines a new group ID. The new group can have any number between
1 and 250. By default, the number is the next one available. There is no need for the
groups to be sequentially numbered or to start at 1.
Delete Group: This removes the group from the list. You are asked if you want to have
references to the group automatically removed.
Reset Group: This removes all relates for the currently highlighted group.
Change ID: This allows the group ID to be changed. This may need to be done if two
databases are being merged together. MPI automatically changes all references to use
the new ID. A gauge is displayed to show the progress of the change.
Relate: Shows the Relate Window. Items marked *on* are operated by inputs related to
the group. When relating inputs to groups, be sure that all relates defined by the group are
allowable for the input.
Copy Relates: Copies the relates and/or message from an input point to the current
group (see Figure 21). The values of the panel, circuit and device are required. Most
conventional circuits use a device number of 0 (zero). Press Copy to copy the information.
Map: Displays and/or updates the Map Window. See section 2.8 Map Window of the
Mircom Programming Interface Database Editor.
Verify List: Displays the Verify List. If there is no Verify List, a requester will appear asking
whether you wish to perform a verification. See section 2.6.5 of the Mircom Programming
Interface Database Editor for a full description of the Verify List and its uses.
