VIFB1 – 02

INSTALLING THE PNEUMATIC COMPONENTS

Laying the hoses

> IFB1-02_BES_V_018474g1_1996-04N - Restored Document - 2011-12-15 <
9604
4. Installation
WARNING
Before installation or maintenance work is
carried out the following must be switched off:
the operating voltage for electronic
components and/or inputs.
The operating voltage for outputs.
PLEASE NOTE
A suitable seal should be placed under each
screw connection or each silencer.
If elbow connectors or multiple distributors
are used the air flow will usually be reduced.
General
• Connecting
1. Push the hose as far as it will go into or
over the screw connection.
2. Pull the locking ring over the hose connec-
tion or tighten the locking screw.
3. For reasons of clarity the hoses should be
grouped together with:
– hose straps or
– multiple hose holders.
• Disconnecting
1. Loosen the locking screw or locking ring
on the connection.
2. Remove the hose.
3. If necessary, replace the screw connection
by blind plugs.
4-7
