SBC84830 Series All-In-One ECX Board User's Manual

4.11 PC Health Status

This section supports hardware monitering that lets you monitor those
parameters for critical voltages, temperatures and fan speed of the
board.
CPU Temperature
The current system CPU temperature will be automatically
detected by the system.
SYSTEM Temperature
Show you the current system1 temperature.
CPU FAN Speed
These optional and read-only items show current speeds in RPM
(Revolution Per Minute) for the CPU fan and chassis fan as
monitored by the hardware monitoring IC.
Vcore +3.3V/+5V/+12V/VBAT(V)/5VSB
Show you the voltage of +3.3V/+5V/+12V.
Award BIOS Utility
47
