request (IRQ) for the onboard parallel port.
SATA Port
If the "PATA IDE Mode" is Primary, it will show " P1, P3 is
Secondary" which means SATA 2 and SATA 4 are
Secondary. If the "PATA IDE Mode " is Secondary, it will
show " P0, P2 is Primary " which means SATA 1 and SATA
3 are Primary.
Press <Esc> to return to the Integrated Peripherals page.
Onboard Device
Scroll to this item and press <Enter> to view the sub menu Onboard
Device.
USB Controller
Enable this item if you are using the USB in the system. You
should disable this item if a higher-level controller is added.
USB 2.0 Controller
Enable this item if you are using the EHCI (USB2.0)
controller in the system.
USB Keyboard Support
Enable this item if the system has a Universal Serial Bus
(USB) controller, and you have a USB keyboard.
AC'97 Audio Select
Use this item to enable or disable the onboard AC'97 Audio
function.
