SBC84830 Series All-In-One ECX Board User's Manual
Pin
29 GND
33 +12V
35 +12V
37 +12V
39 SIO1_RI
41 LPC_FRAME#
43 LPC_DRQ1#
45 GND
47 CLK_33M_SIO2
49 GND
51 INT_PIRQE#
53 INT_PIRQG#
55 PCI_REQ2#
57 GND
59 CLK_33M_PCI2
61 GND
63 PCI_REQ1#
65 +5V
67 PCI_GNT1#
69 PCI_AD31
71 PCI_AD29
73 PCI_AD27
75 PCI_AD25
77 +3.3V
79 PCI_C/BE3#
81 PCI_AD23
83 GND
85 PCI_AD21
87 PCI_AD19
89 +3.3V
91 PCI_AD17
93 PCI_C/BE2#
95 PCI_IRDY#
97 PCI_DEVSEL#
18
Signal Pin
30 GND
34 CLK_100M_PCIE0#
36 GND
38 PWR_PSON#
40 +5V_SBY
42 LPC_AD0
44 LPC_AD1
46 LPC_AD2
48 LPC_AD3
50 INT_SERIRQ
52 +3.3V
54 SMB_DATA_S
56 SMB_CLK_S
58 GND
60 CLK_48M_SIO2
62 GND
64 CLK_33M_PCI1
66 GND
68 INT_PIRQF#
70 PCI_GNT2#
72 +5V
74 P_PLT_RST#
76 GND
78 PCI_PME#
80 PCI_AD30
82 PCI_AD28
84 PCI_AD26
86 GND
88 PCI_AD24
90 PCI_AD22
92 PCI_AD20
94 GND
96 PCI_AD18
98 PCI_AD16
Signal
Jumpers and Connectors
