SBC84830 Series All-In-One ECX Board User's Manual
Graphics
®
Intel 945GM GMCH Gen 3.5 integrated graphic engine
CRT interface for external display devices
Maximum up to 224MB frame buffer sharing system
memory
Maximum display resolution:
LCD backlight control supported
Expansion Slot
ECX expansion interface with SDVO B/C, LPC, two PCI and
one PCIe X1
Ethernet
One RTL8111B Gigabit Ethernet
Wake On LAN (via ATX power supply)
Equipped with RJ-45 interface
Audio
Realtek AC'97 codec audio
MIC-in, Line-out
Power Management
ACPI (Advanced Configuration and Power Interface)
Form Factor
ECX form factor
NOTE: Specifications are subject to change without notice.
Introduction
CRT: 2048 x1536
LVDS: 1600 X1200 (24-bit single/dual
channel LVDS interface)
3
