D6 (Dio6/Rts); D7 (Dio7/Cts) - Digi XBee DigiMesh 2.4 User Manual

AT commands
Default
1

D6 (DIO6/RTS)

Sets or displays the DIO6/RTS configuration (pin 16).
Parameter range
0, 1, 3 - 5
Parameter
0
1
2
3
4
5
Default
0

D7 (DIO7/CTS)

Sets or displays the DIO7/CTS configuration (pin 12).
Parameter range
0, 1, 3 - 7
Parameter Description
0 Disabled
CTS flow control
1
2 N/A
3 Digital input
4 Digital output, low
5 Digital output, high
6 RS-485 Tx enable, low Tx (0 V on transmit, high when idle)
7 RS-485 Tx enable high, high Tx (high on transmit, 0 V when idle)
Default
0x1
XBee/XBee-PRO DigiMesh 2.4 RF Module User Guide
Description
Disabled
RTS flow control
N/A
Digital input
Digital output, low
Digital output, high
I/O settings commands
91
