- Page 1 CONFIDENTIAL WB-20 SMART WIFI MODULE Operation Manual Rev. Description Date Preliminary release 2019/12/13 Define model name 2020/2/6 PE Dept, SHANGHAI TERAOKA ELECTRONIC CO., LTD. 1 of 12...
- Page 2 CONFIDENTIAL Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 3 CONFIDENTIAL Contents 1. General Layout ........................4 2. Features ..........................5 3. Operating Conditions ......................5 4. Connectors ......................... 5 5. Network Setup ........................5 PE Dept, SHANGHAI TERAOKA ELECTRONIC CO., LTD. 3 of 12...
- Page 4 CONFIDENTIAL 1. General Layout Bridge Mode In this mode, module connects AP with WIFI and emission WIFI itself, the ETH port is LAN,PC and other device could connect module with Ethernet cable PE Dept, SHANGHAI TERAOKA ELECTRONIC CO., LTD. 4 of 12...
- Page 5 CONFIDENTIAL 2. Features • Onboard A64 Quad-core ARM Cortex-A53 1.2GHz (Fanless) • 1G DDR3L co-layout memory • 8G co-layout eMMC NAND flash • WIFI 2.4G/5G 802.11a/b/g/n/ac • Bluetooth 4.2 • TF CARD • OS: Android 6.0 3. Operating Conditions • Power Source : DC5V/0.15A •...
- Page 6 CONFIDENTIAL S0.9 AMS STATIC SELECT WIFI TYPE Please always use X key to set it as STATIC S0.10 AMS 000000000000 ENTER WIFI IP1 Set WIFI IP address S0.11 AMS 000000000000 ENTER WIFI SUBNET MASK1 Set WIFI subnet mask S0.12 AMS 000000000000 ENTER WIFI DNS1 Set DNS if needed S0.13 AMS 000000000000...
- Page 7 CONFIDENTIAL B. Modify AMS file Use Notepad++ to open the csv file to edit Below is the data content: 1,,"SM- 120T",1,010010092050,255255255000,192168001001,008008008008,004004004004,1,"TESTTESTTEST",2,"11111111",1,1 92168063050,255255255000,000000000000,000000000000,192168063001,192168063001,000000000000,1,3872,"admin","a dmin",1 Below is the column definiton So that means: Column Column Value Related Data Explaination Code (null) No data = Add or Change "SM-120T"...
- Page 8 2.2.3 WB-20 PC Setting for Transfer AMS File To WB-20, if scale side is not available to input related characters in Rezero+0457: A. Single byte language countries can use P32 key to convert to ASCII code (countries use Standard version) B.
- Page 9 CONFIDENTIAL 2.3.1 Upgrade APK by Lan For example, 1. Rezero+0416=010010092050 2. Set or check AMS FTP status, port, account and password in Rezero+0457 …... S0.17 AMS ALLOW SELECT AM FTP SWITCH S0.18 AMS 3872 SELECT AM FTP PORT S0.19 AMS USER 5 admin S0.20 AMS PWD 5...
- Page 10 CONFIDENTIAL 6. Put scale.apk to root folder 7. Wait for it disconnect, that means the upgrade has been finished. The software is restarting. 8. Use hardware switch to reboot scale. (Do not need to wait for apk restarting) 9. Check current Android apk version (ReZero+100 in Z mode) Z1.0 RESET SALES DAILY RESET SALES DAILY REPORT STE58 BOOT VR1.01...
- Page 11 CONFIDENTIAL 2.3.2 Upgrade APK by WIFI For example, 1. Rezero+0457 …... S0.5 ALLOW SELECT WIFI SWITCH S0.6 SSID 12 TESTTESTTEST S0.7 AMS WPA-PSK SELECT WIFI ENCRYPTION S0.8 PWD 8 11111111 S0.9 STATIC SELECT WIFI TYPE S0.10 AMS 192168063050 EMTER WIFI IP1 S0.11 AMS 255255255000 ENTER WIFI SUBNET MASK1 ……...
- Page 12 CONFIDENTIAL 6. Put scale.apk to root folder 7. Wait for it disconnect, that means the upgrade has been finished. The software is restarting. 8. Use hardware switch to reboot scale. (Do not need to wait for apk restarting) 9. Check current Android apk version (REZERO+100 in Z mode) Z1.0 RESET SALES DAILY RESET SALES DAILY REPORT STE58 BOOT VR1.01...
