Digi XBee DigiMesh 2.4 User Manual page 144

Operate in API mode
Frame data fields
64-bit source (remote) address
Reserved
16-bit source (remote) address
AT commands
Command status
Command data
Checksum
XBee/XBee-PRO DigiMesh 2.4 RF Module User Guide
Offset Example
MSB 5 0x00
6 0x13
7 0xA2
8 0x00
9 0x40
10 0x52
11 0x2B
LSB 12 0xAA
0xFF
13
14 0xFE
MSB 13 0x7D
LSB 14 0x84
15 0x53 (S)
16 0x4C (L)
17 0x00
18 0x40
19 0x52
20 0x2B
21 0xAA
22 0xF4
API frames
144
