Regulatory information
Antennas approved for use with the XBee-PRO DigiMesh 2.4 RF Modules (cable loss is
required)
Type
Part number (description)
Yagi class antennas
A24-Y4NF Yagi (4-
element)
A24-Y6NF Yagi (6-
element)
A24-Y7NF Yagi (7-
element)
A24-Y9NF Yagi (9-
element)
A24-Y10NF Yagi (10-
element)
A24-Y12NF Yagi (12-
element)
A24-Y13NF Yagi (13-
element)
A24-Y15NF Yagi (15-
element)
A24-Y16NF Yagi (16-
element)
A24-Y16RM Yagi (16-
element,
RPSMA
connector)
A24-Y18NF Yagi (18-
element)
Omni-directional class antennas
A24-F2NF Omni-
directional
(fiberglass
base station)
A24-F3NF Omni-
directional
(fiberglass
base station)
XBee/XBee-PRO DigiMesh 2.4 RF Module User Guide
Gain Application*
6.0 dBi Fixed
8.8 dBi Fixed
9.0 dBi Fixed
10.0 dBi Fixed
11.0 dBi Fixed
12.0 dBi Fixed
12.0 dBi Fixed
12.5 dBi Fixed
13.5 dBi Fixed
13.5 dBi Fixed
15.0 dBi Fixed
2.1 dBi Fixed/Mobile
3.0 dBi Fixed/Mobile
United States (FCC)
Minimum Required
separation cable loss
2 m 8.1 dB
2 m 10.9 dB
2 m 11.1 dB
2 m 12.1 dB
2 m 13.1 dB
2 m 14.1 dB
2 m 14.1 dB
2 m 14.6 dB
2 m 15.6 dB
2 m 15.6 dB
2 m 17.1 dB
20 cm 4.2 dB
20 cm 5.1 dB
