Chapter 4 Printer Setup
Media Setup, cont.

Print Setup

In the setup string examples,
a double-headed arrow (as in
"CHAR LENGTH") indicates a
↔
mandatory space characters in the
command line.
Quotation marks (" ") are ASCII
34 dec.
34
Always use ribbons and labels from Intermec. These have
been carefully matched with the printhead. Other ribbons and
labels may shorten the life of the printhead.
Setup string, examples:
Direct thermal printing (Economy grade)
SETUP "SERVICE,PRINT
When setting the printer for thermal transfer printing, two "New
Supplies" setup strings have to be used; one for the transfer ribbon
and another for the receiving face material, for example:
HP07 ribbon:
SETUP "SERVICE,PRINT
Matt coated face stock:
SETUP "SERVICE,PRINT
• Performance
This setting controls the print speed:
- Normal
- High
Normal print speed gives the best printout quality for
demanding layouts, containing for example ladder style bar
codes or fi ne-detailed images. However, high speed gives an
acceptable quality for most applications.
Setup strings, examples:
SETUP "SERVICE,PERFORMANCE,NORMAL" ↵
SETUP "SERVICE,PERFORMANCE,HIGH" ↵
Contrast
•
This setting controls the darkness of the printing on the paper.
The range is 0-10, where 0 is the lightest and 10 is the darkest.
To obtain the best printout quality, the contrast should be
set to 5 (default) when using "New Supplies" setup stringsfor
setting up the printer in regard of ribbon and labels.
Setup string, example:
SETUP "CONTRAST,5" ↵
SUPPLIES,GQ90" ↵
DEFS,NEW
↔ ↔
SUPPLIES,GF100" ↵
DEFS,NEW
↔ ↔
SUPPLIES,GZ0" ↵
DEFS,NEW
↔ ↔
Nominal speed 100 mm/sec.
Nominal speed 150 mm/sec.
Intermec EasyCoder E4 – User's Guide
(4 inches/sec.)
(6 inches/sec.)
