Media Load – Peel-Off, cont.
7
Route the liner around the tear bar and the liner
drive roller and back under the print mechanism
and the lower (rear) guide shaft.
9
1
Close the covers.
Intermec EasyCoder E4 – User's Guide
8
Wind up the liner on the takeup hub and secure
it with the clip. Wind up the liner so the media
10
2 x Feed
2
Print out two blank copies by pressing Feed twice. If
loading media for the fi rst time or when switching
to a new type or brand of media, instead print a test
label as described at the end of this chapter.
Chapter 3
2
becomes tight
Operation
