Chapter 3 Operation
Media Load – Peel-Off, cont.
3
Pull out the clip on the liner takeup hub, then
remove any liner.
5
Check that the media supply roll post is in the
correct position for the size of the media roll. The
post is easier to move if fi rst rotated
Push the new roll as far in as it will go and adjust
the edge guide.
16
2
1
1
/ of a turn.
4
4
Remove any empty core from the media
supply roll post. It is not necessary to remove the
edge guide.
6
40 cm (15 inches)
Remove labels from the fi rst 40 cm (15 inches) of the
liner. Lower the printhead.
