Chapter 4 Printer Setup

Print Location Setup

Recommended Adjustments:
Peel-Off (Label w gaps):
Start Adjust :
Stop Adjust:
Tear-Off (Ticket w mark):
Start Adjust:
Stop Adjust:
Tear-Off (Label w gap):
Start Adjust:
Stop Adjust:
Tear-Off (Var. Length Strip):
Start Adjust:
Stop Adjust:
Tear-Off (Fix Length Strip):
Start Adjust:
Stop Adjust:
Cut-Off (Strip):
Start Adjust:
Stop Adjust:
Cut-Off (between labels):
Start Adjust:
Stop Adjust:
In the setup string examples,
a double-headed arrow (as in
"CHAR LENGTH") indicates a
↔
mandatory space characters in the
command line.
Quotation marks (" ") are ASCII
34 dec.
30
• Media Feed Adjustments
There are two settings that control the amount of blank
media to be fed before the actual printing starts and after it
-119
is completed:
-33
- Start Adjustment
-152
0
-152
0
- Stop Adjustment
-136
+75
Using these two settings, you can, for example, control the media
-136
feed so the printing starts at the top of the label and the media still
+150
can be torn off in the gap between two labels.
Setup strings, examples:
-250 SETUP "DETECTION,FEEDADJ,STARTADJ,-136" ↵
+180 SETUP "DETECTION,FEEDADJ,STOPADJ,75" ↵
-250
+100
This setting feeds out or pulls back a specifi ed length of
media before the printing of a label, ticket, or portion
of continuous stock starts. The value is entered as dots,
where a positive value (no leading minus sign) feeds out
the media and a negative value (leading minus sign) pulls
it back.
This setting works the same way as the Start Adjustment,
but is executed after the printing of a label etc. is com-
pleted.
