Replacing the Printhead, cont.
3
Raise the printhead.
5
3
1
Slide in the new printhead (1), connect the printhead
cable (2), and hook the spring into position (3.)
Intermec EasyCoder E4 – User's Guide
2
Unhook the spring (1), pull the printhead forward
2
Chapter 6
4
1
3
(2), and disconnect the cable (3.)
6
Reload the media and possible transfer ribbon.
