Intermec EasyCoder E4 User Manual page 34

Chapter 4 Printer Setup
Print Location Setup, cont.
Print Window
1 mm
(0.04 inches)
Dot-line on
printhead
X-start
Dot 0
12 mm
(0.47
inches)
32
Origin
(x=0; y=0)
Width (x-dimension)
Path of
Label Stop Sensor &
Label Taken Sensor
FROM
MEDIA SUPPLY
104 mm (4.1 inches)
PRINT PRINT PRINT
WINDOW WINDOW WINDOW
FEED
DIRECTION
max. 114 mm (4.49 inches)
Intermec EasyCoder E4 – User's Guide
9 mm
(0.35 inches)
Dot 831
