7 Mount the Belt
7.1 Assemble the drive wheel
Part name
Drive wheel holder
Drive wheel
R84zz Ball Bearing
M3 x16mm screw
M4 x 25mm screw
M4 washer
M4 lock nut
wing nut
www.geeetech.com
ShenZhen GETECH CO.,LTD
GEEETECH
Part #
#33
#32
#31
#20
#26
#6
#11
#12
Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 – 858
Qty.
3
3
6
3
3
3
3
3
Page
49
