Step 2.
Attach the control board (#50) to the base plate (#A2) with 4 M3 x 12
Screws (#19) and m3 washers (#5).
Note:
It is better to have the fan pointing directly towards the MOSFET located
on the control board (as pictured above).
Don't forget to stick the heat sink(#42) on the chip of the A4988 stepper motor driver
with sticker(#41).
Videos
1.6 Mount the print bed.
Name
www.geeetech.com
ShenZhen GETECH CO.,LTD
GEEETECH
Part #
Qty.
Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 – 858
Page
17
