Step 1.
Place the print head assembly on to the building platform (#M8) aligning it
so then the end stop (#44) and probe (#43) are facing the "X" tower.
Working with the "X" axis first, slide the diagonal rod (#4) on to the on the
Step 2.
rod-end bearing holder located on the assembled print assembly, fixing it
on with a round head screw with pad (#15).
Fix the other end of the diagonal rod (#4) to the carriage located on the "X
Step 3.
axis" tower with a round head screw with pad (#15).
www.geeetech.com
ShenZhen GETECH CO.,LTD
GEEETECH
Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 – 858
Page
57
